Netti V EL

High five for the perfect fit with electric functions!

Netti V combines the advantages of an active and a comfort wheelchair. This configuration has electric adjustment of the recline, the seat tilt and the leg supports, making changes in seating position easier to handle for user or attendant.

The wheelchair has many adjustment possibilities for perfect fitting. Despite changes in the user's body measurement and/or functional level, there is no need to change to another wheelchair.

Flexible seat depth and width
Flexible seat height
Perfect balancing point
Built-in leg abduction
Unique customisation to torso

This innovative design makes it easy to adapt the chair to changing user needs or new users - often even without having to add new accessories.

The electric functions are availble from Q1-2024.

Add to compare
Why choose this chair?
Configuration possibilities
Specifications
Videos
Downloads

Why choose this chair?

Electrical control of tilt, recline and leg supports

Netti V EL and Netti III EL are the only manual wheelchairs on the market which can be fitted with electrical control of seat, back and leg support adjustment.

Low seat height - even with large wheels

Netti V has a unique seat height solution. We can offer a seat height of 386 mm and still mount 24” main wheels and 7” front wheels. This makes it possible to maintain good driving characteristics and enable hand or foot propelling of the chair.

This ensures a great driving experience!

Over the time the health status of the user might change. An active user, who used to hand propel the chair, might be in need of help from an attendant to stay mobile. The seat height can then be changed up to 486 mm by changing the wheel position, but with the same parts.





In other words:

  • 70 mm seat height adjustment without change of wheel position, wheel size, or the need of any extra parts.
  • 100 mm seat height adjustment without change of wheel size, or the need of any extra parts.
  • 169 mm seat height adjustment when changing wheel size and position.





Optimized for the perfect fit

Netti V EL offers many built-in adjustment options making the wheelchair flexible to changing needs - or new users:

LEARN MORE here

70 mm seat height flexibility without changing parts

Netti V provides a unique seat height flexibility, which makes it possible to change the seat height

  • to fit multiple activity levels without changing parts
  • to have low seat height with large wheels for comfortable driving
  • without changing wheel position

The seat height adjustment thereby allows the wheelchair to follow the progression of the user’s illness, from All-round wheelchair propelled by foot or hand to Comfort wheelchair.



Most narrow wheelchair on the market: seat with + 210 mm possible

If you use the wheelchair in its standard seat width, the total width will be 210 mm wider than the seat width.
If you adjust the seat width to the max, total width will be actual frame seat width +260 mm.

Example:

450 mm wheelchair adjusted in seat width 450 mm has a total width of 660 mm
450 mm wheelchair adjsuted in seat width 500 mm has a total width of 710 mm

Accomodates for asymmetries

Stepless sideway adjustment of the head support

To accomodate for an asymmetrical head position, the sidewards adjustable head support adapter can easily be moved on the push bar by loosening the star wheel.











Built-in leg abduction and extension pieces



For Netti V we also offer many leg support solutions. Common for all are that the extension pieces can be adjusted in width in case the user has mobility or positioning challenges at the legs and/or hip/pelvis. The built-in stepless leg abduction of up to 25 mm per side is standard.

For the fitting, the use of the optional pelvic positioner guide might also be of importance to secure that the hips are equally supported.



Adjust to back curvatures

Netti V uses the well-known adjustable back straps for optimum fit to the users back shape.

Furthermore, the back tubes can be positioned in an outward, inward or straight position to fit narrow shoulders (A-shape) or broad shoulders (V-shape) or even an asymmetric position.







LEARN MORE here

Easy-to-use for carers

Netti V is designed to be easy to use in everyday life as well as when the wheelchair is to be fitted for the user upon delivery. This makes it easy to handle for all parties involved.

Just to mention some features that makes this chair extraordinary easy to use:

  • There are only 2 handles - tilt/recline and drum brake handle in one
  • Foot-operated anti tippers
  • Readable scales for easy adjustments
  • Color-marked adjustment points

See our helpfull tutorial videos here

An environmental and economical solution
The same wheelchair can be used for a long time

Due to the design of Netti V, the same wheelchair can be used for a long time. There is no need to change wheelchair when the user’s activity level changes or by minor changes in body messurements.

LEARN MORE here

Who will benefit from this wheelchair?

For users with specific challenges like e.g.

  • Asymmetries like scoliosis
  • Users with A or V shaped upper body
  • Users wishing to propel the chair
  • High requirements in need of comfort and customisation
  • Need for positioning, stabilisation, and posture correction
  • Lacking or limited trunk and body stability
  • Hemiplegia
  • Rheumatic conditions
  • Craniocerebral injuries
  • Leg amputees
  • Limited mobility or muscle strenght
  • Youngsters who are still growing

Key Features

Electrical recline
Electrical tilt
Electrical leg support
100 mm seat height flexibility without changing parts
Tilt: -3 to +30°
Seat depth from 375 to 550 mm
Seat width adjustability of 50 mm
Seat width from 350 to 550 mm
Seat height from 345 to 514 mm

Configuration possibilities

An overview of all the possibilities you have with this wheelchair.

= Standard configuration
= Option
= Not possible

Leg supports
Angle adjustable leg support with calf support and footplates:
Netti Grandis leg support:
Universal leg support:
Netti Dynamic leg support:
Footboard:
Adjustable extension pieces:
Footbox:
Amputation leg support:
Abduction leg support +50 mm:
Electric angle adjustable leg support:
Seat
Sliding seat plate:
Firm seat plate:
Dynamic seat plate:
Comfort seat plate:
Electric tilt function:
Electric seat depth adjustment:
Back
Back cushion options possible:
Back height extension:
H-belt adapter:
Side supports:
Dynamic back option:
Electric back function:
Pelvic belt and harness
Hip belts:
Pelvis stabilizer and other belts from BodyPoint:
H-belt adapter:
Upper body support from Netti and Bodypoint:
Arm support
Revolvable arm support:
Removable arm support:
Height and depth adjustable armrest:
Various arm pad:
Hemi arm support:
Half tray:
Head support
Head support A:
Various head supports:
Head support stabilizer:
Netti Dynamic head support:
Aluminium head support adapter:
Dynamic component
Netti Dynamic head support:
Netti Dynamic seat plate:
Netti Dynamic back:
Libertas flexible back:
Netti Dynamic leg support:
Wheels and brakes
Frame brakes:
Drum brakes:
Anti tippers with pedal:
One hand drive:
Cover
Wipeable Easy Care cover:
Breathable 3D cover:
Various accessories
Device rack for medical aids:
Intravenous rack:

= Standard configuration
= Option
= Not possible

Specifications

Further configuration options can be seen in on the tab "Configuration Possibilities"

= Standard configuration
= Option
= Not possible

General specifications
Seat width:
350, 400, 450, 500 mm
Optional seat width flexibility:
2x -25/ 2x + 12,5/25 mm
Seat depth:
375 - 550 mm
Back height possibilities range:
515 - 613 mm
Seat height range measured to seatplate:
345 - 514 mm
Weight of wheelchair without cushions:
32 kg
Max. load:
136 kg
Max. load for car transport:
136 kg
Tilt angle:
-3° - +30°
Recline angle:
90° - 118°
Leg support length with standard leg support:
320 - 680 mm
Width added to seat width with standard wheels:
+ 210 mm
Total length with standard leg supports:
1000 mm
Arm support height (from seatplate to armpad):
185 - 325 mm
Allowed as seat in a car:

= Standard configuration
= Option
= Not possible

Videos

Head support adjustment - Netti V
Push handles adjustment - Netti V
Recline limiter - Netti V
Seat height adjustment - Netti V
Antitippers - Netti V
Tilt and recline - Netti V
User brakes operation - Netti V
Brake lever height adjustment - Netti V
Attendant brakes operation - Netti V
Tramping Pedal - Netti V
Depth adjustement of back hinges - Netti V
Changing wheel position - Netti V
Leg abduction and seat width adjustment at the leg supports - Netti V
Main wheel width position adjustment - Netti V
Seat width expansion at arm support level - Netti V
Back width adjustment - Netti V
Back cushion adjustment - Netti V
Back extender, mounting - Netti V
Back extender adjustment - Netti V
Back rest shape - Netti V
Back recline limiter - Netti V
Arm support adjustment - Netti V
Dynamic recline lock - Netti V
Balance point adjustment - slide main wheel bracket - Netti V
Balance point adjustment - seat unit - Netti V
Leg supports angle adjustment - Netti V
Leg support length adjustment - Netti V
Foot plate angle adjustment - Netti V
Calf support height adjustment - Netti V
Adjust the velcro straps to the user's back
Mounting 16" wheels
Seat Depth regulation 400-550 mm - Netti V
Brake position adjustment - Netti V
Brake bracket adjustment - Netti V
