Netti 4U CED

The Netti 4U CED is the most advanced chair of the Netti 4U family. The wheelchair is characterized by its lightweight and narrow design making the chair ideal for narrow doorways and tight indoor spaces. The chair can easily be transported in mid-range cars.

Modern design
Excellent ergonomic solutions
Many configuration options
Ideal for hip asymmetries

Add to compare
Why choose this chair?
Configuration possibilities
Spare part catalogue

Why choose this chair?

Dynamic seating options

Involuntary movements often cause several challenges for wheelchair users and attendants for example sliding and thus often need of repositioning.

This can be accommodated by including dynamic seating solutions. For the Netti 4U CED the following dynamic options are available:

  • Dynamic head support
  • Dynamic back support
  • Dynamic leg support

If the movement patterns include pelvic movements, we recommend a complete Netti Dynamic System including a dynamic seat unit. For this purpose, we offer the Netti Dynamic CED.

Clinical tests show that dynamic options increase the user’s quality of life giving him the opportunity to spend longer time in the chair in a good seating position thus enabling him to take part in every day life.

By allowing the chair to adapt to the user’s movement, the wear of the chair is also reduced.

Read more about the choice of gas cylinder strengths.

Many leg support options

A good positioning of the feet is the first step in creating an upright and stable seating position. And even head control is influenced by the leg positioning. Therefor many leg support options are important if you want to create the best possible seating situation allowing the user to socialize and improve respiration.

Netti 4U CED with its many leg support options, is a good choice if you have users with challenges like:

  • Pointed foot
  • Contractions
  • Restless legs
  • Extra need of support
  • Involuntary movements
  • Amputation
  • Asymmetries
54 mm seat width flexibility

Seat width reduction (2x15 mm) and seat with expansion (2x 12 mm) give room for growth and make the Netti 4U CED economical in use. These options can also be used to create optimum stability and position.

Combined with the flexibility in seat depth, this makes Netti 4U CED suitable for users of many sizes with functional seat widths of 320 mm to 500 mm.

For larger seat widths, we offer Netti 4U CED XL and Netti III HD and Netti III XHD.

Seat depth from 375-500 mm

Netti 4U CED offers both short and long seat depth. This makes it suitable for e.g. tall and skinny users.

Equipped with comfort pads, it can have a seat width as low as 320 mm, and still have a seat depth up to 500 mm. The seat depth can be adjusted by 75 mm without changing the components.

Adaptable for asymmetries

Netti 4U CED offers the most options to compensate for different asymmetries.

Hip asymmetries can be accommodated through different adjustment of the extension pieces offering a stable fundament.

Curved back shape can be supported through the Velcro back with 6 individually adjustable straps as well as the possibility to position the back cushion according to the user’s back shape.

Total width only +180 mm

Netti 4Us are the most narrow and lightweight wheelchairs on the market.

Total seat width of the wheelchair

  • Seat width +180 mm with standard wheels
  • Seat width +195 mm with drum brake wheels
  • Seat width +170 mm with 16”/12,5” wheels


The ergonomic push bow also makes the wheelchair ideal for tight indoor spaces.

Who will benefit from this wheelchair?

User group Netti Campus

The Netti 4U CED is ideal for long-term sitting (8+ hours per day). It will fit both young and geriatric users of all sizes. The chair works well for users being transferred by hoist or to the side.

For users with specific challenges like e.g.

  • Hip rotation or pelvic rotation
  • Asymmetries like scoliosis
  • Kyphosis
  • Users with neurological disabilities like spasticity and restlessness


For users needing specific accessories like e.g.

  • Medical device
  • Special leg support solutions
  • Firm aluminium back
  • Dynamic components

Key Features

Ergonomic push bow
Adjustable velcro back
Flexible arm support
Extenders for leg length compensation
Seat width flexibility

Configuration possibilities

An overview of all the possibilities you have with this wheelchair.

= Standard configuration
= Option
= Not possible

Leg supports
Angle adjustable leg support with calf support and footplates:
Netti Grandis leg support:
Universal leg support:
Netti Dynamic leg support:
Adjustable extension pieces:
Amputation leg support:
Abduction leg support +50 mm:
Electric angle adjustable leg support:
Sliding seat plate:
Firm seat plate:
Dynamic seat plate:
Comfort seat plate:
Electric tilt function:
Back cushion options possible:
Back height extension:
H-belt adapter:
Side supports:
Dynamic back option:
Libertas option:
Electric back function:
Pelvic belt and harness
Hip belts:
Pelvis stabilizer and other belts from BodyPoint:
H-belt adapter:
Upper body support from Netti and Bodypoint:
Arm support
Revolvable arm support:
Removable arm support:
Height and depth adjustable armrest:
Various arm pad:
Hemi arm support:
Half tray:
Head support
Head support A:
Various head supports:
Head support stabilizer:
Netti Dynamic head support:
Aluminium head support adapter:
Dynamic component
Netti Dynamic head support:
Netti Dynamic seat plate:
Netti Dynamic back:
Libertas flexible back:
Netti Dynamic leg support:
Wheels and brakes
Frame brakes:
Brake lever extension:
Drum brakes:
Anti tippers without pedal:
Anti tippers with pedal:
Frame extension:
One hand drive:
One hand brake:
Easy Wheel:
Ad on drive and Powered assist
E-Drive option:
E-Move option:
Wipeable Easy Care cover:
Breathable 3D cover:
Various accessories
Device rack for medical aids:
Intravenous rack:

= Standard configuration
= Option
= Not possible


Read more about the choice of gas cylinder strengths.

= Standard configuration
= Option
= Not possible

General specifications
Seat width:
350, 400, 430, 450, 500 mm
Optional seat width flexibility:
2x -15/+ 2x +12 mm
Seat depth:
425 - 500 (375 - 450) mm
Back height possibilities range:
500 - 600 mm
Seat height range measured to seatplate:
440 - 500 mm
Weight of wheelchair without cushions:
29 kg
Max. load:
160 (130) kg
Max. load for car transport:
136 (130) kg
Tilt angle:
-5° - +20°
Recline angle:
92° - 137°
Leg support length with standard leg support:
320 - 680 mm
Width added to seat width with standard wheels:
+180 mm / DB: +195 mm / 12+16'' = +170 mm mm
Total length with standard leg supports:
1020 mm
Arm support height (from seatplate to armpad):
265 - 355 mm
Allowed as seat in a car:

= Standard configuration
= Option
= Not possible


See a presentation of the Netti 4U CED

Spare part catalogue

Here you have the possibility of downloading a sparepart catalogue for precisely the Netti wheelchair you are looking at right now.

Please be aware that the download can take up to app. 2 minutes and that the catalogue contains app. 250 pages.
The pages are indexed and you can use the PDF tools for a specific search on either item number or name.

The online version offers more information like weight, EAN number, additional information and filter and search functions.

Do not hesitate to contact us if you have any questions.
