Head support E
From 08/2023 the head support E will be delivered in an updated and improved version:
No tools needed to adjust the angle of the side-wings*
Hinges covered for high hygienic standard
Side supports app. 130 mm (40 mm shorter than the previous head support E)
Head support E gives lateral side of the scull and is typically used when the head has the tendency to drop to the side. It's a strong therapeutic head support with easy to adjust side supports. For users who need a head support which can control the head position.
*the version with short sides is still with tools
Items to Order
Head support E with either short right or short left side is a discontinued product, sold while stock last.
This product is a special adapted solution, please contact customer service for information about price.
| Pos. | Description | Fabric | Unit | Item no. | |
|---|---|---|---|---|---|
| Head support with adjustable sides E | 3D | Piece | 94238 |
|
|
| Head support with adjustable sides E - short right side | 3D | Piece | 88860 |
|
|
| Head support with adjustable sides E - short left side | 3D | Piece | 88866 |
|
|
| Head support with adjustable sides E | Easy Care | Piece | 94033 |
|
|
| Head support with adjustable sides E - short right side | Easy Care | Piece | 88863 |
|
|
| Head support with adjustable sides E - short left side | Easy Care | Piece | 88869 |
|
| Pos. | Description | Fabric | Depth | Unit | Item no. | |
|---|---|---|---|---|---|---|
| Head support with adjustable sides E and horizontal bar | 3D | 150 mm | Piece | 94233 |
|
|
| Head support with adjustable sides E and horizontal bar | Easy Care | 150 mm | Piece | 94032 |
|
|
| Head support with adjustable sides E and horizontal bar | 3D | 250 mm | Piece | 94235 |
|
|
| Head support with adjustable sides E and horizontal bar | Easy Care | 250 mm | Piece | 94234 |
|
|
| Head support with adjustable sides E and horizontal bar | 3D | 380 mm | Piece | 94237 |
|
|
| Head support with adjustable sides E and horizontal bar | Easy Care | 380 mm | Piece | 94236 |
|
| Pos. | Description | Fabric | Depth | Unit | Item no. | |
|---|---|---|---|---|---|---|
| Head support with adjustable sides E - longer left side - and horizontal bar | 3D | 150 mm | Piece | 88847 |
|
|
| Head support with adjustable sides E - longer left side - and horizontal bar | Easy Care | 150 mm | Piece | 88850 |
|
|
| Head support with adjustable sides E - longer left side - and horizontal bar | 3D | 250 mm | Piece | 88848 |
|
|
| Head support with adjustable sides E - longer left side - and horizontal bar | Easy Care | 250 mm | Piece | 88851 |
|
|
| Head support with adjustable sides E - longer left side - and horizontal bar | 3D | 380 mm | Piece | 88849 |
|
|
| Head support with adjustable sides E - longer left side - and horizontal bar | Easy Care | 380 mm | Piece | 88852 |
|
| Pos. | Description | Fabric | Depth | Unit | Item no. | |
|---|---|---|---|---|---|---|
| Head support with adjustable sides E - longer right side - and horizontal bar | 3D | 150 mm | Piece | 88853 |
|
|
| Head support with adjustable sides E - longer right side - and horizontal bar | Easy Care | 150 mm | Piece | 88856 |
|
|
| Head support with adjustable sides E - longer right side - and horizontal bar | 3D | 250 mm | Piece | 88854 |
|
|
| Head support with adjustable sides E - longer right side - and horizontal bar | Easy Care | 250 mm | Piece | 88857 |
|
|
| Head support with adjustable sides E - longer right side - and horizontal bar | 3D | 380 mm | Piece | 88855 |
|
|
| Head support with adjustable sides E - longer right side - and horizontal bar | Easy Care | 380 mm | Piece | 88858 |
|
| Pos. | Description | Height | Unit | Item no. | Price | |
|---|---|---|---|---|---|---|
1 |
Head support vertical bar with tube | 200 mm | Piece | 41401 | €48.00 |
|
1 |
Head support vertical bar with tube | 350 mm | Piece | 41402 | €48.00 |
|
1 |
Head support vertical bar with tube | 500 mm | Piece | 41403 | €93.00 |
|
2 |
Plast plug round | - | Piece | 20509 | €2.00 |
|
3 |
Latch lever M6x30 | - | Piece | 20282 | €9.00 |
|
| Pos. | Description | Height | Unit | Item no. | Price | |
|---|---|---|---|---|---|---|
| Head support vertical bar | 300 mm | Piece | 92901 | €48.00 |
|
| Pos. | Description | Unit | Item no. | Price | |
|---|---|---|---|---|---|
1 |
Latch lever M6x30 | Piece | 20282 | €9.00 |
|
2 |
Washer M6 | Piece | 20063 | €2.00 |
|
3 |
Starwheel M8 | Piece | 91056 | €9.00 |
|
4 |
Washer D20xd8.4x1.2 mm | Piece | 29305 | €3.00 |
|
5 |
Plug 20x30x11.5 mm | Piece | 20852 | €3.00 |
|
| Latch lever M6x16 mm | Piece | 20097 | €9.00 |
|
| Pos. | Description | Depth | Unit | Item no. | Price | |
|---|---|---|---|---|---|---|
| Head support horizontal bar | 250 mm | Piece | 20318 | €56.00 |
|
|
| Head support horizontal bar | 380 mm | Piece | 20372 | €73.00 |
|
The head support is ment for users:
- Users needing a good lateral support to maintain head position
- Users with head deformities
- Users with contracted neck muscles
Each head support can be fitted to each Netti wheelchair by using the head support adapter. To adjust the head support in height you need to loosen the red latch lever by turning the lever anticlockwise until you can move the vertical bar up-or downwards. Adjust the vertical bar according to your need and turn the red lever clockwise to fasten the bar again. A solid version of the head support adapter made of aluminium is available. With this you can fix the height with a bolt to avoid unwanted changes in position.
To adjust the head support in depth, loosen the red latch lever of the horizontal tube. Loosen the red latch lever by turning the lever anticlockwise until you can move the horizontal tube front-or backwards. Adjust the horizontal tube according to your need and turn the red lever clockwise to fasten the head support again.
As an additional adjustment you can move the head support free in space. Loosen the red star wheel by turning the lever anticlockwise until you can move the head support upholstery free in space. Adjust the head support according to your need and turn the star wheel clockwise to fasten the tube again.
The head support adapter can be move to the right or left adjusting the positioning of the head support to the user.
3D
Breathable, elastic and durable. The 3D mesh structure enhances the microclimate, ventilates and reduces heat build-up. This strengthens the skin and the resistance of the underlying tissue against internal and external influences, such as pressure and shear. 100% PES (Polyester).
EASY CARE
Durable, breathable, elastic, wipeable and hygienic. PES (Polyester) + PU.
Does it fit my Netti?
If you do not know, which Netti you have, please check the serial number.
You will find the serial no. on a label at the lower cross bar. It writes xxx-xxxxxx.
The first 3 digits of the serial number will help you determine which Netti wheelchair you have.
Please check our FAQ for a list of all serialnumbers and Netti model.
